150W Waterproof Led Power supply

Model

YJV-150-12

YJV-150-24

YJV-150-36

Output

Dc output voltage

12V

24V

36V

Output voltage tolerance

±3%

±3%

±3%

Rated output current

12.5A

6.3A

4.2A

Output current range

0~12.5A

0~6.3A

0~4.2A

Output power

150W

151W

151W

Ripple and the noise

120mVp-p

150mVp-p

180mVp-p

Dc voltage adjustable scope

±10%

±10%

±10%

Start, rise, keep time

1000ms,30ms,24ms/230VAC

Input

Input voltage range

180~264VAC 47~63Hz,255~373VDC

Exchange input current

1.8A/230VAC

efficiency

82%

84%

85%

Impulse current

Cold start current 40A/230VAC

Leakage current

<2.5mA/240VAC

Protection

Short Circuit

Protection type:recovers automatically after fault conditions is removed

Overload

Overload protection@145~160%above peak rating

Over Temperature

protection typer:shut down o/p voltage.re-power on to recover

Environment

Working temperature, humidity

-10C~+60C;20%~90%RH(Please refer to reduce the specified number load curve )

Keep temperature humidity

-20C~+85C;10%~95%RH No condensation

Vibrate resistance

10~500Hz,2G 10min./ 1 cycle time, 60 minutes, the axis

Security

With stand Voltage

Compression sex

Between input and output:1.5KVAC

Insulation resistance

Between input and output:100M Ohms/500VDC

Security

Safety standards

CE Mark(LVD),IP67

EMC standard

EN 55015:2006; EN 61547:1995+A1:2000 ;EN 61000-3-2:2006; EN61000-3-2:1995+A2:2005

EN 61347-1:2008 EN 61347-2-13:2006

Connect the line request

Input:H03VV-F 3G*0.75mm Brown&blue&kelly VDE(200mm) Output:H03VV-F 2*0.75mm Black & Red VDE(300mm*4)

Other

Weight/Size

1.2kg/ 210*70*40(L*W*H)

packaging

Inner carton package, 15pcs cartaon box in a big outer carton box(15pcs/Box)

Note

1.All the parameters in has not specified, all is in 230 VAC voltage input, rated load and 25C conditions measuring income value.
2.Ripple and noise voltage is in 20 MHz bandwidth oscilloscope with 1 to 2 inches twisted pair end with 0.1 mu and 47 u when capacitance measurement.
3.Tolerance is voltage setting error, the voltage adjustment rate and adjust the sum total of the current rate.
