Product Description
ATTEN AT8586 Advanced Hot Air Soldering Station, SMD Rework Station, 750W, 2 in 1
Features
- Hot air station and soldering station set (the two of them can work separately without mutual interference).
- Digital LED temperature display, so that the operation more convenient and accurate.
- Self-examine and errors check, with screen reminding to guide people to repair.
- Adopts Closed-loop control sensors for temperature accuracy and stability.
- Ideal for safe demolition solder QFP, PLCC, SOP, BGA and other chips and components which are temperature-sensitive.
- Intelligent cooling system, after the shutdown delay completion of the work of air, air temperature lower than 100 °c automatically cut off power supply.
- Use of imported air pump for low vibration, noise-free design and maintain a quiet working environment.
- Static elimination design, prevent PCB board damage due to static or electric leakage.
Rework Station Description:
- Hot air station and soldering station set (the two of them can work separately without mutual interference).Digital LED temperature display, so that the operation more convenient and accurate. Self-examine and errors check, with screen reminding to guide people to repair. Adopts Closed-loop control sensors for temperature accuracy and stability. Ideal for safe demolition solder QFP, PLCC, SOP, BGA and other chips and components which are temperature-sensitive. Intelligent cooling system, after the shutdown delay completion of the work of air, air temperature lower than 100 °c automatically cut off power supply. Use of imported air pump for low vibration, noise-free design and maintain a quiet working environment. Static elimination design, prevent PCB board damage due to static or electric leakage.
Technical Specifications:
- Voltage: AC 220V ±10% 50Hz
- Whole Power: 750W
Hot Air SMD Reworks Station
- Voltage: AC 220V ±10% 50Hz
- Output power: 700W
- Temperature range:100°c-55°c
- Temperature stability:± 5°c
- Air output: 120L/min (The MAX.)
Soldering Station
- Voltage: AC 26V 50Hz
- Output power: 50W
- Temperature range:200°c-480°c
- Temperature stability:± 2°c Static (No wind, no load)
- Leak resistance of soldering tip :< 2Ω
- Leak voltage of soldering tip :< 3mv
