Product Description
Compact Digital Scouting Camera
-Unique side Prep Sensor design provides wider angle and enhances response speed
-Included Detachable Battery Box; Flexible when need longer operating time
-Perform in the most extreme temperatures |
| - Features:
- 5 Mega Pixels CMOS sensor with interpolated to 12 Mega Pixels
- Sharp and bright color pictures in daytime and clear black/white pictures at night
- Ultra low standby power consumption. Extremely long in-field life(in standby power, up to 3 months with 4xAA batteries and 6 months with 8xAA batteries
- Unique side Prep Sensor design provides wider sensing angle and enhances camera's response speed
- Perform in the most extreme temperatures from -22F to 158F
- Impressively quickly trigger time (1 second)
- Backpack-looking tree grabber makes mounting and aiming a snap
- Serial Number function enables you to code locations in the photos. This helps multi-camera user identify the location when reviewing the photos
- Date. time, temperature and moon phase can be stamped in the pictures
- Lockable and password protected
- Specification:
- Lens :F=3.1; FOV=52degrees; Auto IR-Cut
- IR-Flashlight: 65 Feet/20 Meters
- TFT Display Screen: 48x35.69mm (2.36inch);480(RGB)*234DOT; 16.7M color
- Operation Keypad: 6 keys
- Memory: SD Card (8MB ~16GB)
- Picture Size: 5MP = 2560x1920 (sensor) & 12MP 4000x3000 (interpolated)
- Video Size: 640x480: 20fps; 320x240: 20fps
- PIR Sensitivity: PIR with 3 sensitivity levels: High/Normal/Low
- PIR Sensing Distance: 65ft/20m(Below +25C/+77F at the Normal Level)
- Preparation PIR Sensing Angle: Left and right light beams form an angle of 100 degrees.
- Shot PIR Sensing Angle: 35 degrees
- Operation Mode: Day/Night
- Trigger Time: 1 Second (When using the 2G SD card)
- Triggering Interval: 0sec. - 60min. Programmable
- Shooting Numbers: 1~3
- Video Length: 1-60sec. Programmable
- Camera+Video: First take Picture and then take Video
- Playback Zoom In: 1~16 times
- Time Stamp: On /Off, include serial No./ temperature and moon phase
- Timer: On /Off Time Lapse Programmable
- Password: 4 Protection Numbers
- Device Serial No.: 4 Digits and 26 alphabet Set by Yourself
- Periodic Shot: 1 Second~24Hours
- Power Supply: 4*AA,Can add to 8*AA(Need the additional battery box)
- Stand-by Current: 0.4mA
- Stand-by Time: 3~6 Months(4*AA~8*AA)
- Auto Power Off: Auto power off in 2 minutes while no keypad controlling.
- Power Consumption: 150mA (+500mA when IR LED lights up)
- Low Battery Alarm: 4.2~4.3V
- Interface: TV out (NTSC); USB; SD Card Holder; 6V DC External
- Fix Method: Belt, Tripod Nail
- Waterproof: IP54
- Operation Temperature: -30 ~+70C/-22~+158F
- Operation Humidity: 5% ~ 95%
- Certificate: FCC & CE & RoHS
| Package Include | Quantity | | Detachable Battery Box | x 1 | | Scouting Camera | x 1 | | Strap | x 1 | | User Manual | x 1 | | USB Cable | x 1 | | AV Cable | x 1 |
|
HD Infrared Wildlife Camera DVR with Motion Sensor (Invisible IR) - 12.0MP VGA 940nm LED |
|
WARRANTY
We take great pride in our products. We always stand behind our promises. We provide a leading warranty term and service. Buying a Ltl Acorn product, you are covered under a limited warranty.
We guarantee our products to be free of defects in materials and workmanship for a limited warranty of the original purchase date. This warranty does not cover consumer caused damages such as misuse, abuse, improper handling or installation, or repairs attempted by someone other than our authorized technicians.
We will, at our option during the warranty period, repair your camera or replace it with the same or comparable model free of charge. This warranty only extends to the original retail buyer from our authorized dealer. Purchase receipt or other proof of the date of the original purchase is required to receive warranty benefits. The warranty on any replacement product provided under the original warranty shall be for the remaining portion of the warranty period applicable to the original product.
This warranty extends solely to failures due to defects in materials or workmanship under normal use. It does not cover normal wear of the product.
If you need to return a Ltl Acorn product under this warranty, please contact your dealer or our distributor.
