Note: Please tell us you need US Plug or EU Plug Power Adaptor as soon as you pay for the order, From today(2013-12-4), we will send you the new version to you, the picture as we showed in the description.Thanks for your understanding in advance.
- The HD1TO1LR1 converter allows the HD Source connected to single HD Display and adds extra one L+R and SPDIF audio out port.
- One HDMI input converted to one HDMI+ Audio (SPDIF+R/L)output
- Output audio support: SPDIF+R/L analog Audio Output
- Input Resolution: up to 1080P(50/60Hz)
- HDMI to achieve the synchronization of audio signal separation. There are PASS / 2.0CH / 5.1CH three kinds of audio mode options
- LED indication: when source or sink is working, LED relative to is light.
- No loss of quality
- Installs in minutes
- Need DC5V/1A power supply
- HDMI resolution: 24/50/60fs/1080p/1080i/720p/576p/576i/480p/480i
- Support video color format: 24bit/deep color 30bit,36bit
- Audio output: L/R+SPDIF
- Max bandwidth: 225MHz
- Max baud rate: 6.75Gbps
- Input/Output TMDS signal: 0.5~1.5Volts p-p(TTL)
- Input/Output DDC signal: 5Volts p-p (TTL)
- Input cable distance: 15m AWG26 HDMI standard cable
- Output cable distance: 20m AWG26 HDMI standard cable
- Max working current: 500mA
- Power adapter format: Input:AC (50HZ, 60HZ) 100V-240V; Output: DC5V/1A
- Operating Humidity range: 5 to 90%RH (No Condensation)
- Dimension (L x W x H): 84.5X61.8X21 (mm)
- Weight: 35g
Operating and Connecting:
- To use one hdmi cable to connect the HD Source with the input HDMI port.
- To connect the converter hdmi output port with the HD Display.
- To use one audio cable to connect the converter R/L port with the audio equipment.
- To use the optical cable to connect the SPDIF port with the audio equipment.
- To connect the converter with 5V DC power adaptor.
1 X New HDMI to HDMI + Audio (RL+SPDIF) Conveters Adapter Support PASS 2.0CH 5.1CH
1 X 5V Power Adaptor
1 X Manual
SKU: WG1036 (new version)
