Free sea shipment mdf cutting cnc machine
Seller Promise:
Product ID: 597001355 Free sea shipment mdf cutting cnc machine Picture
Woodworking cnc router machine
Machine instruction:
wooden engraving machine is the high cost performance of a affordable products . Choose the domestic first-class air cooled 6 KW main spindle motor and 7.5 KW inverter , the high torque motor drive , imported linear 30 party rail . The control system adopts offline DSP operation , do not take up the computer resources .
Widely application :
1 .Furniture industry : solid wood furniture , wooden door , cabinet .
2 .Wooden products processing : wooden Speakers , wooden Clock , wardrobe , Sports Equipment .
3 .Musical instrument : 3D surface engraving and shape cutting .
4 .Electric industry : circuit board , insulation material , LED display screen .
Machine parameter:
Model Name | TSW1325 |
Table size | 1440*3040mm |
X Y Z axis working area | 1300*2500*200mm |
X-Y movement | Rack and pinion drive |
Z movement | German Ball screw drive |
Guide | Taiwan Hiwin Liner 30 square n guide |
Max speed | 35000mm/Min |
Max working speed | 20000mm/Min |
Repeat positioning accuracy | ±0.05mm |
System Resolution | ±0.02mm |
Spindle | 6.0kw air cool spindle |
Spindle speed | 0- 18000rpm/min |
Working Voltage | AC380/50Hz |
Command code | HPGL,G code |
Drive motors | stepper |
Collet | Φ12.7mmΦ.6mm, Φ3.175mm(option) |
Computer interface | USB 2.0 |
Software | Type3 ,Artcam ,Ucancam |
Controls | Ncstudio(optioanl DSP) |
Assistant Equipment | Water pump,air pump (Optional) |
Packing dimensions | 2200mm*3200mm*1850mm 1400kg |
Machine process:
Machine parts
Machine option parts
Machine sample:
after sales service:
1. 24 hours service on Internet and Telephone, free instructions and problem solving
2.free trainging how to use.
3, User-friendly English manual or operating video for machine using and maintaining
4. on-the-spot training and installation can be met if required
