Sinewave Electronic expert in develop and produce high freqency green engery switch amplifier and digital audio equipment,We have rich experience in developing proaudio and Hi-Fi audio more than 10 years,lots of audiophile over world are our loyal friends,we have designed and produced types of electronic audio equipment,ODM/OEM are our good at cooperation.Professional victory, leading innovation.We constantly strives to provide the excellent products and customer service.
- 1. Advance Sigma Delta Auto adaptive circuit inside
- 2.Stage based on the new type high stability support circuit,high stable and high level audio.
- 3. 100V PA amp output, suit for 70v or 100v products .
- 4.A wide set of features for plug and play implementation into applications such as pro pa amp and other high voltage output equipment.
- 5.Auto Fast Reset circuit inside,support the chip full power and safty
- 6.High efficience Resonant HB audio SMPS integrated,over current protect andother protect function enable.
- 7.Perfect protection support,UVP/OVP/OTP/OCP/DCP
- 8.Lower EMI design, suit for powered mixer or other proaudio equipment.
- 9.ac select,110v or 230v ac
- 10.dc battery reverse connect protect function
POWER OUT: 1×500W/ 100v/1%THD+N
FREQUENCY RESPONSE: THD+N ≤0.05% / 20-20KHz / ±1dB/10W
INPUT SENSITIVITY: 0dB(1Vrms)
POWER SUPPLY: AC: 110V OR 230V 50 OR 60 Hz
INPUT: differential input
incude heasink height
- The above specifications are only for reference,upgrade anytime, design and specification are subject to change without prior notice,if you have any questions, please contact with our technology department.
- Every showing product have user manual, pls send mail to us for it.
